    Non standard products can be customized Varied End faces WHITE Fiber Optic Ceramic Ferrule

    Ask Lasest Price
    Brand Name : Hicorpwell
    Model Number : HCW-Ferrules
    Certification : CE & Rohs
    Delivery Time : 12
    Payment Terms : TT/Westunion
    Supply Ability : 5000 per Month
    • Product Details
    • Company Profile

    Non standard products can be customized Varied End faces WHITE Fiber Optic Ceramic Ferrule

    Here's a brief overview of the ceramic ferrules used in these connectors:


    1. FC Ceramic Ferrule:

    * Typically made of zirconia (zirconium oxide)
    * Ferrule outer diameter: 2.5 mm
    * Fiber bore diameter: 125 μm (for single-mode fibers)
    * Threaded design for connection
    * Commonly used in telecommunications and premises cabling

    2. SC Ceramic Ferrule:

    * Often made of zirconia or alumina
    * Ferrule outer diameter: 2.5 mm
    * Fiber bore diameter: 125 μm (for single-mode fibers)
    * Push-pull design for connection
    * Widely used in local area networks (LANs) and data centers

    3. LC Ceramic Ferrule:

    * Typically made of zirconia
    * Ferrule outer diameter: 1.25 mm (smaller than FC and SC)
    * Fiber bore diameter: 125 μm (for single-mode fibers)
    * Compact push-pull design
    * Commonly used in high-density applications, such as data centers and premises cabling

    4. ST Ceramic Ferrule:

    * Often made of zirconia or alumina
    * Ferrule outer diameter: 2.5 mm
    * Fiber bore diameter: 125 μm (for single-mode fibers)
    * Bayonet-style twist-lock design
    * Used in older fiber optic systems, but largely replaced by newer connector types
